Description
| Dimensions & Weight | |
|---|---|
| Depth: | 66 cm |
| Height: | 35.1 cm |
| Weight: | 34 kg |
| Width: | 44.1 cm |
| Environmental Parameters | |
|---|---|
| Humidity Range Operating: | 5 – 95% (non-condensing) |
| Humidity Range Storage: | 5 – 95% (non-condensing) |
| Max Operating Temperature: | 40 °C |
| Max Storage Temperature: | 70 °C |
| Min Operating Temperature: | 0 °C |
| Min Storage Temperature: | -40 °C |
| Expansion / Connectivity | |
|---|---|
| Expansion Slots: | 3 (total) / 3 (free) x fabric module slot ¦ 2 (total) / 2 (free) x Chassis Management Module (CMM) slot ¦ 8 (total) / 8 (free) x Expansion Slot |
| General | |
|---|---|
| Device Type: | Switch – with 3 x Fan Trays, 18 x Fans, Cable Manager, X462 2-post Rack Rail Kit |
| Enclosure Type: | Rack-mountable 8U |
| Subtype: | 100 Gigabit Ethernet |
| Miscellaneous | |
|---|---|
| Compliant Standards: | CISPR 22 Class A, EN 61000-3-2, IEC 61000-3-2, IEC 61000-3-3, EN 61000-3-3, ICES-003 Class A, FCC, UL 60950-1, VCCI Class A, GB 9254, AS/NZS CISPR 22, IEC 60950-1:2005 Second Edition, CSA 22.2 No. 60950-1, EN 60950-1:2006+A1:2010+A2:2013+A11:2009+A12:2011, IEC 60950-1:2005 + A1:2009 + A2:2013, EN 55022 Class A, FCC CFR47 Part 15 B Class A, IEC 60825:2007, UL 62368-1 Second Edition, CISPR 32:2012 Class A, EN 55032:2012 Class A, EN 62368-1:2014 |
| Power | |
|---|---|
| Installed Qty: | 0 (installed) / 4 (max) |
| Power Device: | Internal power supply – hot-plug |
| Power Redundancy: | Yes |
| Power Redundancy Scheme: | N+1 |
