Description
| Dimensions & Weight | |
|---|---|
| Depth: | 49.5 cm |
| Height: | 8.9 cm |
| Weight: | 13.2 kg |
| Width: | 48.26 cm |
| Environmental Parameters | |
|---|---|
| Humidity Range Operating: | 10 – 90% (non-condensing) |
| Max Operating Temperature: | 40 °C |
| Min Operating Temperature: | 5 °C |
| Expansion / Connectivity | |
|---|---|
| Expansion Bays: | 24 (total) / 24 (free) x hot-swap – 2.5″ SFF |
| Interfaces: | 4 x 8Gb Fibre Channel ¦ 2 x USB (management) ¦ 2 x Ethernet 1000Base-T (management) – RJ-45 ¦ 2 x SAS 6Gb/s – 26 pin 4x Shielded Mini MultiLane SAS (SFF-8088) |
| General | |
|---|---|
| Device Type: | Hard drive array |
| Enclosure Type: | Rack-mountable – 2U |
| Hard Drive | |
|---|---|
| Type: | No HDD |
| Miscellaneous | |
|---|---|
| Compliant Standards: | FCC Class A certified, CISPR 22 Class A, CISPR 24, EN 61000-3-2, GS, EN 61000-3-3, EN55022 Class A, CCC, FCC Part 15, ICES-003 Class A, UL 60950-1, IEC 60950-1, EN 60950-1, CSA C22.2 No. 60950-1-03, WEEE, RoHS, EN55024 Class A, VCCI Class A, KN24, KN22 Class A, China RoHS, CNS 13438 |
| Features: | Firmware upgradable |
| Power | |
|---|---|
| Max Supported Qty: | 2 |
| Power Consumption Operational: | 337 Watt |
| Power Device: | 2 x internal power supply – hot-plug |
| Power Redundancy: | Yes |
| Power Redundancy Scheme: | 1+1 |
| Voltage Required: | AC 120/230 V – 50/60 Hz |
| Storage | |
|---|---|
| HDD Array External Interface: | 8Gb Fibre Channel |
| Max Supported Capacity: | 28.8 TB |
| Maximum LUNs: | 512 |
| Storage Controller | |
|---|---|
| Cache / Buffer Size (Max): | 4 GB |
| Data Transfer Rate: | 600 MBps |
| Installed Qty: | 2 |
| Interface Type: | SAS 6Gb/s |
| RAID Level: | RAID 0, RAID 1, RAID 3, RAID 5, RAID 6, RAID 10, RAID 50 |
| Type: | RAID |
| Storage Controller (2nd) | |
|---|---|
| Installed Qty: | 2 |
| System Requirements | |
|---|---|
| OS Required: | Red Hat Linux, SUSE Linux Enterprise Server, Microsoft Windows Server 2008 SP2, Microsoft Windows Server 2012 |
