Description
| Chassis | |
|---|---|
| Supported Devices / Modules Qty: | 24 |
| Supported Drives: | SAS-2 |
| Dimensions & Weight | |
|---|---|
| Depth: | 67.6 cm |
| Height: | 8.795 cm |
| Weight: | 21.6 kg |
| Width: | 48.3 cm |
| Environmental Parameters | |
|---|---|
| Humidity Range Operating: | 10 – 90% (non-condensing) |
| Max Operating Temperature: | 40 °C |
| Min Operating Temperature: | 5 °C |
| Expansion / Connectivity | |
|---|---|
| Expansion Bays: | 24 (total) / 24 (free) – 2.5″ SFF |
| Expansion Slots: | 2 (total) / 2 (free) x PCIe |
| Interfaces: | 4 x 8Gb Fibre Channel ¦ 1 x Ethernet 1000 (management) |
| General | |
|---|---|
| Device Type: | Hard drive array |
| Enclosure Type: | Rack-mountable – 2U |
| Miscellaneous | |
|---|---|
| Cables Included: | 2 x SAS cable – 2 m |
| Compliant Standards: | FCC Class A certified, C-Tick, BSMI CNS 13438 Class A, EN 60950, IEC 61000-3-2, RoHS, IC Class A, UL 60950-1 Second Edition, KCC, WEEE, FCC CFR47 Part 15 B, GOST-R, cTUVus, TUV T, BSMI Class A, IEC 61000-3-3:2008, EN 61000-3-3:2008, ICES-003 issue 4 Class A, EN 61000-3-2:2006+A1:2009+A2:2009, VCCI Class A, China RoHS, EN 62479:2010, EN60950-1:2006 + A11:2009, BSMI CNS 14336-1, EN55022:2010 Class A, IEC 60950-1:2005 Second Edition, CISPR 24:2010, CISPR 22:2008, AS/NZS CISPR 22:2009, CAN/CSA-C22.2 No. 60950-1, EN55024:2010 |
| Included Accessories: | 4x 8Gb Short Wave FC SFP transceivers |
| Pricing Type: | Field installation |
| Processor | |
|---|---|
| Type: | 2 x 1.8 GHz |
| Storage | |
|---|---|
| HDD Array External Interface: | 8Gb Fibre Channel |
| Storage Controller | |
|---|---|
| Cache / Buffer Size (Max): | 48 GB |
| Data Transfer Rate: | 600 MBps |
| Installed Qty: | 2 |
| Interface Type: | SAS 6Gb/s |
| RAID Level: | RAID 0, RAID 1, RAID 5, RAID 6 |
| Type: | RAID |
| Storage Controller (2nd) | |
|---|---|
| Installed Qty: | 2 |
| System Requirements | |
|---|---|
| OS Required: | IBM AIX, HP-UX, SUSE Linux Enterprise Server, Microsoft Windows Server, Red Hat Enterprise Linux, HP OpenVMS, Ubuntu, Oracle Solaris, Citrix XenServer, Oracle Linux, Red Hat Enterprise Virtualization |
