Description
| Chassis | |
|---|---|
| Installed Devices / Modules Qty: | 0 |
| Supported Devices / Modules Qty: | 24 |
| Supported Drives: | SAS |
| Dimensions & Weight | |
|---|---|
| Depth: | 67.61 cm |
| Height: | 8.795 cm |
| Weight: | 21.6 kg |
| Width: | 48.3 cm |
| Environmental Parameters | |
|---|---|
| Humidity Range Operating: | 10 – 90% (non-condensing) |
| Max Operating Temperature: | 40 °C |
| Min Operating Temperature: | 5 °C |
| Expansion / Connectivity | |
|---|---|
| Expansion Bays: | 24 (total) / 24 (free) – 2.5″ SFF |
| Expansion Slots: | 2 (total) / 2 (free) x PCIe |
| Interfaces: | 4 x 16Gb Fibre Channel ¦ 2 x Ethernet 1000 (management) ¦ 2 x Ethernet 1000 |
| General | |
|---|---|
| Device Type: | Hard drive array |
| Enclosure Type: | Rack-mountable – 2U |
| Hard Drive | |
|---|---|
| Type: | No HDD |
| Miscellaneous | |
|---|---|
| Cables Included: | 2 x SAS cable – 2 m |
| Compliant Standards: | FCC Class A certified, C-Tick, RoHS, IC Class A, UL 60950-1 Second Edition, KCC, WEEE, FCC CFR47 Part 15 B, GOST-R, cTUVus, TUV T, BSMI Class A, IEC 61000-3-3:2008, EN 61000-3-3:2008, EN 61000-3-2:2006+A1:2009+A2:2009, VCCI Class A, China RoHS, EN 62479:2010, EN55024:2010, CNS13438:2006, CNS 14336, EN60950-1:2006 + A11:2009, RRA Class A, EN55022:2010 Class A, IEC 60950-1:2005 Second Edition, IEC 61000-3-2:2005, VCCI – V-3/2014.04, CISPR 24:2010, ICES-003 issue 5 Class A, CISPR 22:2008, AS/NZS CISPR 22:2009, CAN/CSA-C22.2 No. 60950-1 |
| Included Accessories: | 2 x rail kit, 4x 16Gb Short Wave FC SFP+ transceivers |
| Processor | |
|---|---|
| Type: | 2 x 2.4 GHz |
| Storage | |
|---|---|
| HDD Array External Interface: | 16Gb Fibre Channel |
| Storage Controller | |
|---|---|
| Installed Qty: | 2 |
| Interface Type: | SAS |
| RAID Level: | RAID 0, RAID 1, RAID 5, RAID 6 |
| Type: | RAID |
| Storage Controller (2nd) | |
|---|---|
| Installed Qty: | 2 |
