HPE – JH148A – 5510 48G PoE+ 4SFP+ HI 1-slot Switch – Switch – L3

Zapytaj o cenę

Category: HP Tags: HPE, JH, Switch

Description
Reviews (0)

Description

Dimensions & Weight
Depth:	36 cm
Height:	4.37 cm
Weight:	7.5 kg
Width:	44 cm

Environmental Parameters
Humidity Range Operating:	10 – 90% (non-condensing)
Humidity Range Storage:	5 – 95% (non-condensing)
Max Operating Temperature:	45 °C
Max Storage Temperature:	70 °C
Min Operating Temperature:	0 °C
Min Storage Temperature:	-40 °C

Expansion / Connectivity
Expansion Slots:	1 (total) / 1 (free) x Expansion Slot
Installed Modules Qty (Max):	0 (installed) / 1 (max)
Interfaces:	48 x 1000Base-T RJ-45 ¦ 1 x console RJ-45 management ¦ 4 x 10Gbit LAN SFP+

General
Authentication Method:	Secure Shell (SSH), RADIUS, TACACS, Secure Shell v.2 (SSH2)
Capacity:	IPv4 routing table entries: 32768 ¦ IPv6 routing table entries: 16384
Compliant Standards:	IEEE 802.3, IEEE 802.3u, IEEE 802.3i, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3af, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.3ae, IEEE 802.3ac, IEEE 802.1s, IEEE 802.1ad, IEEE 802.1v, IEEE 802.1ab (LLDP), IEEE 802.1ak, IEEE 802.3at, IEEE 802.3az
Device Type:	Switch – 48 ports – L3 – Managed – stackable
Enclosure Type:	Rack-mountable 1U
Features:	Flow control, Layer 3 switching, DHCP support, ARP support, MPLS support, auto-uplink (auto MDI/MDI-X), Weighted Round Robin (WRR) queuing, IPv6 support, Class-Based Weighted Fair Queuing (CBWFQ), Weighted Fair Queuing (WFQ), Weighted Random Early Detection (WRED), sFlow, Spanning Tree Protocol (STP) support, Rapid Spanning Tree Protocol (RSTP) support, Virtual Route Redundancy Protocol (VRRP) support, Multiple Spanning Tree Protocol (MSTP) support, DHCP snooping, Quality of Service (QoS), RADIUS support, Rapid Ring Protection Protocol (RRPP) support, Equal-Cost Multipath (ECMP), Bidirectional Forwarding Detection (BFD), STP Root Guard, IPv4 support, Deficit Weighted Round Robin (DWRR), Strict Priority (SP), 802.1x authentication, Type of Service (ToS), MACsec support, Smoothed Deficit Weighted Round Robin (SDWRR), Virtual Private LAN Service (VPLS)
Flash Memory:	512 MB
Jumbo Frame Support:	Yes
MAC Address Table Size:	32K entries
Performance:	Routing/switching capacity: 336 Gbps ¦ Throughput: 250 Mpps
PoE Budget:	1440 W
Ports:	48 x 10/100/1000 (PoE+) + 4 x 10 Gigabit SFP+
Power Over Ethernet (PoE):	PoE+
RAM:	2 GB SDRAM
Remote Management Protocol:	SNMP 1, SNMP, RMON, Telnet, SNMP 3, SNMP 2c, HTTP, SSH, SSH-2, CLI
Routing Protocol:	OSPF, RIP, IS-IS, BGP, VRRP, PIM-SM, static IP routing, PIM-DM, OSPF for IPv6, OSPFv3, PIM-SSM, ECMP, RIPng, IS-ISv6, MPLS, Bidirectional Forwarding Detection (BFD)
Status Indicators:	Power, system, operation mode
Subtype:	Gigabit Ethernet

Miscellaneous
Compliant Standards:	EN55024, AS/NZS 60950-1, RoHS, FCC CFR47 Part 15, UL 60950-1, IEC 60950-1, EN 60950-1, EN 60825-1, GB 4943, EN 61000-4-29, Directive 2004/108/EC, ANSI C63.4-2009, EN 60825-2, EN 61000-3-3:2008, EN 61000-3-2:2006+A1:2009+A2:2009, EN 61000-4-6:2009, EN 61000-4-11:2004, EN 300 386 V1.6.1, VCCI V-3/2013.04 Class A, CISPR 24:2010, EN 55022:2010 Class A, EN 300 386, CAN/CSA-C22.2 No. 60950-1
Pricing Type:	Remarketed
Rack Mounting Kit:	Included

Power
Installed Qty:	0 (installed) / 2 (max)
Power Consumption Operational:	670 Watt
Power Device:	Internal power supply
Power Redundancy:	Optional
Power Redundancy Scheme:	1+1 (with optional power supply)
Voltage Required:	AC 120/230 V
