HPE – JH325A – 5130 24G PoE+ 4SFP+ 1-slot HI Switch – Switch – verwaltet

Zapytaj o cenę

Category: HP Tags: HI SWITCH, HPE, JH, SFP, Switch, verwaltet

Description
Reviews (0)

Description

Dimensions & Weight
Depth:	46 cm
Height:	4.37 cm
Weight:	12.5 kg
Width:	43.99 cm

Environmental Parameters
Humidity Range Operating:	10 – 90% (non-condensing)
Humidity Range Storage:	5 – 95% (non-condensing)
Max Operating Temperature:	45 °C
Max Storage Temperature:	70 °C
Min Operating Temperature:	-5 °C
Min Storage Temperature:	-40 °C

Expansion / Connectivity
Expansion Slots:	1 (total) / 1 (free) x Expansion Slot
Installed Modules Qty (Max):	1 (installed) / 1 (max)
Interfaces:	24 x 1000Base-T RJ-45 ¦ 4 x 10Gbit LAN SFP+ ¦ 1 x serial (console) ¦ 1 x USB 2.0 ¦ 1 x management (LAN) RJ-45

General
Authentication Method:	Secure Shell (SSH), RADIUS, TACACS, TACACS+, Secure Shell v.2 (SSH2), HWTACACS
Capacity:	Simultaneous VLANs: 4094 ¦ IPv4 routing table entries: 32768 ¦ IPv6 routing table entries: 16384
Compliant Standards:	IEEE 802.3, IEEE 802.3u, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3x, IEEE 802.1w, IEEE 802.1x, IEEE 802.3ae, IEEE 802.1s, IEEE 802.1ad, IEEE 802.3ah, IEEE 802.1ab (LLDP), IEEE 802.1ak, IEEE 802.3az
Device Type:	Switch – 24 ports – Managed – stackable
Enclosure Type:	Rack-mountable 1U
Encryption Algorithm:	SSL
Features:	Flow control, DHCP support, ARP support, VLAN support, auto-uplink (auto MDI/MDI-X), Syslog support, Weighted Round Robin (WRR) queuing, IPv6 support, sFlow, Spanning Tree Protocol (STP) support, Rapid Spanning Tree Protocol (RSTP) support, Virtual Route Redundancy Protocol (VRRP) support, Multiple Spanning Tree Protocol (MSTP) support, Port Aggregation Protocol (PAgP) support, Access Control List (ACL) support, Quality of Service (QoS), Committed Access Rate (CAR), DHCP server, Device Link Detection Protocol (DLDP) support, Equal-Cost Multipath (ECMP), STP Root Guard, IPv4 support, LLDP support, Smart Link Pass-Through, dynamic ARP protection, DHCP protection, port isolation, non blocking ports, Strict Priority (SP), Generic Attribute Registration Protocol (GARP), Intelligent Resilient Framework Technology (IRF), OpenFlow support, IP source guard
Flash Memory:	512 MB
Jumbo Frame Support:	9KB
Performance:	Throughput: up to 154.8 Mpps ¦ Routing/switching capacity: 208 Gbps
PoE Budget:	740 W
Ports:	24 x 10/100/1000 (PoE+) + 4 x 10 Gigabit SFP+
Power Over Ethernet (PoE):	PoE+
RAM:	2 GB SDRAM
Remote Management Protocol:	SNMP 1, RMON 1, RMON 2, RMON 3, RMON 9, Telnet, SNMP 3, SNMP 2c, HTTPS, TFTP, SSH-2, CLI, SCP
Routing Protocol:	RIP-1, RIP-2, IGMPv2, IGMP, PIM-SM, IGMPv3, MSDP, MLD
Subtype:	Gigabit Ethernet

Miscellaneous
Compliant Standards:	VCCI, EN 61000-3-2, AS/NZS 60950-1, RoHS, UL 60950-1, IEC 60950-1, EN 60950-1, EN 60825-1, GB 4943, ANSI C63.4-2009, EN 60825-2, EN 61000-3-3:2008, EN 61000-4-5:2006, EN 61000-4-6:2009, EN 61000-4-11:2004, EN 300 386 V1.6.1, VCCI V-3/2013.04 Class A, CISPR 24:2010, EN 55022:2010 Class A, FCC CFR47 Part 15 A, EN 61000-4.4:2012, CAN/CSA-C22.2 No. 60950-1
Rack Mounting Kit:	Included

Power
Installed Qty:	0 (installed) / 2 (max)
Power Consumption Operational:	650 Watt
Power Device:	Internal power supply
Power Redundancy:	Optional
Power Redundancy Scheme:	1+1 (with optional power supply)
Voltage Required:	AC 120/230 V (50/60 Hz)
