Description
| Dimensions & Weight | |
|---|---|
| Depth: | 26.07 cm |
| Height: | 4.4 cm |
| Weight: | 1.74 kg |
| Width: | 25.3 cm |
| Environmental Parameters | |
|---|---|
| Humidity Range Operating: | 15 – 95% (non-condensing) |
| Humidity Range Storage: | 15 – 95% (non-condensing) |
| Max Operating Temperature: | 40 °C |
| Max Storage Temperature: | 70 °C |
| Min Operating Temperature: | 0 °C |
| Min Storage Temperature: | -40 °C |
| Expansion / Connectivity | |
|---|---|
| Interfaces: | 6 x 1000Base-T RJ-45 ¦ 2 x 10 Gigabit Ethernet / 10 Gigabit Ethernet SFP+ RJ-45/SFP+ |
| General | |
|---|---|
| Compliant Standards: | IEEE 802.1Q, IEEE 802.1p, IEEE 802.3x, IEEE 802.1w, IEEE 802.3at, IEEE 802.3az |
| Device Type: | Switch – 6 ports – Managed |
| Enclosure Type: | Desktop, rack-mountable, wall-mountable 1U |
| Encryption Algorithm: | SSL |
| Features: | Full duplex capability, Layer 2 switching, auto-negotiation, auto-uplink (auto MDI/MDI-X), port mirroring, half duplex mode, full duplex mode, Quality of Service (QoS), DHCP client, 2MB packet buffer, Network Timing Protocol (NTP) |
| Jumbo Frame Support: | 9220 bytes |
| MAC Address Table Size: | 16000 entries |
| Performance: | Throughput: 119 Mpps ¦ Switching capacity: 160 Gbps ¦ Latency (100 Mbps): 6.8 µs ¦ Latency (1000Base-T): 2.9 µs ¦ Latency (10 Gbps): 6.8 µs |
| Ports: | 6 x 1 Gigabit / 10 Gigabit Ethernet + 2 x 10 Gigabit Ethernet / 10 Gigabit Ethernet SFP+ |
| Processor: | 1 x ARM Cortex-A9: 600 MHz |
| RAM: | 128 MB DDR3 SDRAM |
| Remote Management Protocol: | SNMP 1, SNMP 2c, HTTPS |
| Subtype: | 10 Gigabit Ethernet |
| Miscellaneous | |
|---|---|
| Compliant Standards: | CISPR 24, EN 61000-3-2, IEC 61000-3-2, IEC 61000-3-3, IEC 61000-4-11, IEC 61000-4-2, IEC 61000-4-3, IEC 61000-4-4, IEC 61000-4-5, IEC 61000-4-6, IEC 61000-4-8, EN 61000-3-3, EN55024, UL 60950, RoHS, IEC 60950-1, EN 60950-1, WEEE, CSA C22.2 No. 60950-1-07 Second Edition, VCCI Class A, CNS 13438, ICES-003 issue 5 Class A, EN 60825-1:2007, FCC CFR47 Part 15 B Class A, EN 55032:2015 |
| Localisation: | English / Europe |
| MTBF: | 64.5 years |
| Rack Mounting Kit: | Included |
| Power | |
|---|---|
| Power Consumption Operational: | 42.8 Watt |
| Power Device: | Internal power supply |
| Voltage Required: | AC 120/230 V (50/60 Hz) |
