Description
| Chassis | |
|---|---|
| Installed Devices / Modules Qty: | 2 |
| Supported Devices / Modules Qty: | 12 |
| Supported Drives: | SAS-2 |
| Dimensions & Weight | |
|---|---|
| Depth: | 66 cm |
| Height: | 28 cm |
| Weight: | 57.9 kg |
| Width: | 73.6 cm |
| Environmental Parameters | |
|---|---|
| Humidity Range Operating: | 10 – 90% (non-condensing) |
| Max Operating Temperature: | 40 °C |
| Min Operating Temperature: | 5 °C |
| Sound Emission: | 55 dBA |
| Environmental Standards | |
|---|---|
| ENERGY STAR Certified: | Yes |
| Expansion / Connectivity | |
|---|---|
| Expansion Bays: | 12 (total) / 10 (free) – 3.5″ LFF |
| Interfaces: | 4 x Ethernet 10Gb (iSCSI) / 16Gb Fibre Channel ¦ 2 x mini-USB 2.0 (management) ¦ 2 x Ethernet 1000Base-T (management) – RJ-45 ¦ 2 x SAS |
| General | |
|---|---|
| Device Type: | Solid state / hard drive array |
| Enclosure Type: | Rack-mountable – 2U |
| Hard Drive | |
|---|---|
| Capacity: | 2 x 800 GB |
| Features: | Mixed-Use |
| Type: | SSD |
| Miscellaneous | |
|---|---|
| Compliant Standards: | CISPR 22 Class A, CISPR 24, EN 61000-3-2, EN55022, GS, EN 61000-3-3, EN55024, CCC, FCC Part 15, UL 60950-1, IEC 60950-1, EN 60950-1, WEEE, RoHS, CAN/CSA C22.2 No. 60950-1-03, VCCI Class A, KN24, KN22 Class A, CNS 13438 Class A, ICES-003:2004 Class A |
| Features: | Systems Insight Manager (SIM) |
| Software Included: | HPE Advanced Data Services Suite, HPE 3PAR Virtual Copy, HPE MSA Remote Snap Software |
| Power | |
|---|---|
| Max Supported Qty: | 2 |
| Power Consumption Operational: | 432 Watt |
| Power Device: | 2 x internal power supply – hot-plug |
| Power Redundancy: | Yes |
| Voltage Required: | AC 120/230 V |
| Storage | |
|---|---|
| Max Supported Capacity: | 960 TB |
| Maximum LUNs: | 512 |
| Storage Capacity Details: | Raw 960 TB |
| Total Array Capacity: | 1.6 TB |
| Storage Controller | |
|---|---|
| Cache / Buffer Size (Max): | 8 GB |
| Data Transfer Rate: | 600 MBps |
| Installed Qty: | 2 |
| Interface Type: | SAS 6Gb/s |
| RAID Level: | RAID 1, RAID 5, RAID 6, RAID 10 |
| Type: | RAID (iSCSI) |
| Storage Controller (2nd) | |
|---|---|
| Installed Qty: | 2 |
| System Requirements | |
|---|---|
| OS Required: | HP-UX, SuSe Linux, Apple MacOS X, Microsoft Windows, Red Hat Enterprise Linux, HP OpenVMS, Microsoft Windows Server 2012, VMware ESXi 5.x, Microsoft Windows Server 2012 R2, Microsoft Windows Server 2012 R2 with Hyper-V, VMware ESXi 6.x |
