Description
| Chassis | |
|---|---|
| Installed Devices / Modules Qty: | 2 |
| Supported Devices / Modules Qty: | 24 |
| Supported Drives: | SAS-2 |
| Dimensions & Weight | |
|---|---|
| Depth: | 49.5 cm |
| Height: | 8.9 cm |
| Weight: | 18.4 kg |
| Width: | 44.7 cm |
| Environmental Parameters | |
|---|---|
| Humidity Range Operating: | 10 – 90% (non-condensing) |
| Max Operating Temperature: | 40 °C |
| Min Operating Temperature: | 5 °C |
| Sound Emission: | 55 dBA |
| Environmental Standards | |
|---|---|
| ENERGY STAR Certified: | Yes |
| Expansion / Connectivity | |
|---|---|
| Expansion Bays: | 24 (total) / 22 (free) – 2.5″ SFF |
| Interfaces: | 4 x Ethernet 10Gb (iSCSI) / 16Gb Fibre Channel ¦ 2 x mini-USB 2.0 (management) ¦ 2 x Ethernet 1000Base-T (management) – RJ-45 ¦ 2 x SAS |
| General | |
|---|---|
| Device Type: | Solid state / hard drive array |
| Enclosure Type: | Rack-mountable – 2U |
| Hard Drive | |
|---|---|
| Capacity: | 2 x 800 GB |
| Features: | Mixed-Use |
| Type: | SSD |
| Miscellaneous | |
|---|---|
| Compliant Standards: | CISPR 22 Class A, CISPR 24, EN 61000-3-2, EN55022, GS, EN 61000-3-3, EN55024, CCC, FCC Part 15, UL 60950-1, IEC 60950-1, EN 60950-1, WEEE, RoHS, CAN/CSA C22.2 No. 60950-1-03, VCCI Class A, KN24, KN22 Class A, CNS 13438 Class A, ICES-003:2004 Class A |
| Features: | Systems Insight Manager (SIM) |
| Software Included: | HPE Advanced Data Services Suite |
| Power | |
|---|---|
| Max Supported Qty: | 2 |
| Power Consumption Operational: | 390 Watt |
| Power Device: | 2 x internal power supply – hot-plug |
| Power Redundancy: | Yes |
| Power Redundancy Scheme: | 1+1 |
| Voltage Required: | AC 120/230 V – 50/60 Hz |
| Processor | |
|---|---|
| CPU: | No CPU |
| Storage | |
|---|---|
| Max Supported Capacity: | 960 TB |
| Maximum LUNs: | 512 |
| Total Array Capacity: | 1.6 TB |
| Storage Controller | |
|---|---|
| Cache / Buffer Size (Max): | 8 GB |
| Data Transfer Rate: | 600 MBps |
| Installed Qty: | 2 |
| Interface Type: | SAS 6Gb/s |
| RAID Level: | RAID 1, RAID 5, RAID 6, RAID 10 |
| Type: | RAID (iSCSI) |
| Storage Controller (2nd) | |
|---|---|
| Installed Qty: | 2 |
| System Requirements | |
|---|---|
| OS Required: | HP-UX, SuSe Linux, Red Hat Enterprise Linux, Microsoft Windows Server 2012, Microsoft Windows Server 2012 R2, Microsoft Windows Server 2016 |
