Description
| Chassis | |
|---|---|
| Installed Devices / Modules Qty: | 0 |
| Supported Devices / Modules Qty: | 24 |
| Supported Drives: | SAS-2 |
| Dimensions & Weight | |
|---|---|
| Depth: | 55.6 cm |
| Height: | 8.7 cm |
| Weight: | 19 kg |
| Width: | 48.3 cm |
| Environmental Parameters | |
|---|---|
| Humidity Range Operating: | 20 – 80% |
| Max Operating Temperature: | 35 °C |
| Min Operating Temperature: | 10 °C |
| Expansion / Connectivity | |
|---|---|
| Expansion Bays: | 24 (total) / 24 (free) x hot-swap – 2.5″ |
| Interfaces: | 6 x SAS 6Gb/s (input) ¦ 2 x SAS 6Gb/s (output) ¦ 4 x USB ¦ 4 x Ethernet 1000 |
| General | |
|---|---|
| Device Type: | Hard drive array |
| Enclosure Type: | Rack-mountable – 2U |
| Hard Drive | |
|---|---|
| Capacity: | 0 |
| Type: | Hot-swap |
| Miscellaneous | |
|---|---|
| Compliant Standards: | NEBS level 3, ETSI |
| Power | |
|---|---|
| Max Supported Qty: | 2 |
| Power Device: | 2 x internal power supply – hot-plug |
| Power Redundancy: | Yes |
| Power Redundancy Scheme: | N+N |
| Voltage Required: | AC 120/230 V – 50/60 Hz |
| Storage | |
|---|---|
| HDD Array External Interface: | SAS 6Gb/s, iSCSI (1 GbE) |
| Storage Controller | |
|---|---|
| Cache / Buffer Size (Max): | 8 GB |
| Installed Qty: | 2 |
| Interface Type: | SAS 6Gb/s |
| RAID Level: | RAID 0, RAID 1, RAID 5, RAID 6, RAID 10 |
| Type: | RAID |
| Storage Controller (2nd) | |
|---|---|
| Installed Qty: | 2 |
