Description
WiFi standard
–
10/100/1000 Mbps RJ-45 ports
4 x LAN/DMZ, 2 x WAN, 1 x SFP
USB 3.0 ports
2
Console port
DB9
Rack-mountable
Yes
Fanless
Yes
System Capacity & Performance*1
SPI firewall throughput (Mbps)*2
1,800
VPN throughput (Mbps)
450
VPN IMIX Throughput (Mbps)*3
160
IPS throughput (Mbps)*4
1,100
Anti-Malware throughput (Mbps)*4
570
UTM throughput (Anti-malware & IPS, Mbps)*4
550
Max. TCP concurrent sessions*5
600,000
Recommended gateway-to-gateway IPsec VPN tunnels
50
Max. concurrent IPsec VPN tunnels*6
100
Concurrent SSL VPN users
60
VLAN interface
16
Wireless Specifications
Standard compliance
–
Wireless frequency
–
Radio
–
SSID number
–
No. of antenna
–
Antenna gain
–
Data rate
–
Key Features
Security Service
Sandboxing*7
Yes
Reputation Filter*7
Yes
IPS*7
Yes
Application Patrol*7
Yes
Email Security*7
Yes
Web filtering*7
Yes
SecuReporter*7
Yes
Collaborative Detection & Response*7
Yes
SSL (HTTPS) Inspection
Yes
Geo Enforcer
Yes
2-Factor Authentication
Yes
Device Insight
Yes
Security Profile Sync*7
Yes
VPN Features
VPN
IKEv2, IPSec, SSL, L2TP/IPSec
Microsoft Azure
Yes
Amazon VPC
Yes
WLAN Management
Default Number of Managed AP
8
Recommend max. AP in 1 AP Group
20
Secure WiFi Service*7
Yes
Maximum No. of Tunnel-Mode AP
10
Maximum No. of Managed AP
40
Management & Connectivity
Nebula Cloud Mode
Yes
Nebula Cloud Monitoring Mode
Yes
Device HA Pro
–
Link Aggregation (LAG)
–
Hotspot Management*7
Yes
Ticket printer support*9/ Support Qty (max.)
Yes (SP350E) / 10
Concurrent device logins (default/max.)*7*8
200
Power Requirements
Power input
12V DC, 2.5A max.
Max. power consumption (Watt Max.)
13.3
Heat dissipation (BTU/hr)
45.38
Physical Specifications
Item
Dimensions (WxDxH)(mm/in.): 272 x 187 x 36/10.7 x 7.36 x 1.42
Weight (kg/lb.): 1.4/3.09
Packing
Dimensions (WxDxH)(mm/in.): 427 x 247 x 73/16.81 x 9.72 x 2.87
Weight (kg/lb.): 2.23 (W/O breacket), 2.42 (W/ breacket)
Included accessories
Power adapter
Rack mounting kit
Environmental Specifications
Operating
Temperature: 0°C to 40°C / 32°F to 104°F
Humidity: 10% to 90% (non-condensing)
Storage
Temperature: -40°C to 70°C/-40°F to 158°F
Humidity: 10% to 90%(non-condensing)
MTBF (hr)
529,688.2
Acoustic noise
–
Certifications
EMC
FCC Part 15 (Class B)
CE EMC (Class B)
C-Tick (Class B)
BSMI
Safety
LVD (EN60950-1)
BSMI
